AONano XP Series

masthead-inner-wave-mob masthead-inner-wave

Additional Information

Features & Benefits:

The all-in-one design makes the laser more compact and reduces the total weight. It saves space for installation on the customer side, lowers the integration cost and simplifies the installation process. The water-cooled design allows the laser to work reliably in various harsh and extreme environments and makes the laser to be the ideal candidate for the 7×24 non-stop production needs.

The output power of 30W, 40W, and up to 60W are available for selection. With the pulse width of ~ 2 ns, high repetition rate up to 2 MHz, it is the perfect candidate for various application areas, including solar cell processing, battery electrodes welding, glass drilling, and so on.

AONano XP 532
Specification 50W-500K 60W-2000K 70W-1000K
Wavelength (nm) 532
Average Power (Watts) >50W@500KHz 60W@2000KHz 70W@1000KHz
Energy (µJ) >100 >30 >70
Specified Repetition Rate (kHz) 500 2000 1000
Repetition Rate (kHz) 100-500 100-2000 100-1000
Pulse Width (ns) 20~40 customizable ~3
Beam Quality (M²) <1.2
Beam Roundness (%) >90
Beam Diameter (mm)   ~2.5
Beam Divergence (mRad) <1
Point Stability (µrad/°C) <20
Polarization Ratio 100:1 Linear, Vertical
Pulse-to-Pulse Stability (% RMS) <3
Average Power Stability (% over 12 hours) <3
Cold Start Warm-Up (mins.) <30
Standby Warm-Up <10
Operational Temperature Range (°C) 15 to 35
Operation Humidity Range (%) 20 to 80, non-condensing
Storage Temperature Range (°C) -20 to 50
Storage Humidity Range (%) 20 to 80, non-condensing
Input Voltage (VDC)/Rated Power(W) 24/450
Communication RS232
Cooling Water
Laser head (kg) 20
