AONano Compact Series Air-cooled
Additional Information

Features & Benefits

This is the intelligent version of our air-cooled AONano Compact-355 laser serials. With the intelligent features listed below, the long-term stability of the laser is significantly improved, and the service time/cost is greatly reduced.

All-in-one format: the optical cavity and electrical controller are integrated into a single box.

Power monitoring: the laser output power is monitored and consequently the real-time power reading is available in the laser GUI and RS232-command.

Auto-optimization: the laser output power can be auto-optimized with the feature of power monitoring. This means that the laser output power can be recovered by auto-optimization if it drops to a level below the predefined threshold. If the power cannot be recovered, the laser will report an alarm. This can significantly reduce the service time and cost.

Crystal indexing: there are multiple spots available for use on the THG crystal. The spot indexing can be controlled manually or automatically by a predefined sequence. There are five spots available on the THG crystal, which means the laser lifetime can be extended by five times.

The AONano Compact-355 series laser is a perfect candidate for various laser micromachining applications. It is a great cost-effective combination of high reliability and high performance.

AoNano Compact(i) 355
Specification 3W-50K 5W-50K
Wavelength (nm) 355
Average Power (watts) >3W@50KHz >5W@50KHz
Energy (µj) >60 >100
Specified Repetition Rate(kHz) 50
Repetition Rate (kHz) 30
Pulse Width (ns) <15
Beam Quality (M²) <1.2
Beam Roundness (%) >90
Beam Diameter (mm) ~0.45
Beam Divergence (mRad) <1.5
Point Stability (µrad/°C) <20
Polarization Ratio 100:1 Linear, Horizontal
Pulse-to-Pulse Stability (%RMS) <3
Average Power Stability (% over 12 hours) <3
Cold Start Warm-Up (mins.) <40
Standby Warm-Up (mins.) <10
Operational Temperature Range (°C) 15-35°C
Operation Humidity Range (%) 20-80, non-condensing
Storage Temperature Range (°C) -20 to 50
Storage Humidity Range (%) 20-80, non-condensing
Input Voltage (VDC)/Rated Power(W) 12/350
Power Consumption(W) <110 <130
Communication RS232
Cooling Air
Laser head (kg) 6.8
