AONano Precision (S) Series
Additional Information

Features & Benefits

Based on the existed Precision technology platform, the upgraded Precision(S) has a wide range of applications. It features a compact size, good compatibility, and a real-time power monitoring func- tion. The new Precision(S) series still possess the excellent beam quality (M2 <1.2) and the ultra-long lifetime. It provides efficient and high-quality laser processing.

The Precision(S) lasers adopt AOC’s world-leading intra-cavity harmonic generation technology. It has the highest harmonic generation conversion efficiency in the industry. The laser power can be optimized at high repetition frequency. Thus, the laser can be used in many applications and improve the processing efficiency for the customers. The laser can be controlled by TTL signals and PWM signals. The laser output power can be controlled through PWF in the laser GUI or the duty cycle of external PWM signals.

The Precision(S) lasers are the best choice for precision micro-machining, fly marking, FPC/PCB cutting, and other applications.

AONano precision (s)

AONano Precision(S) 355
Specification 15W – 50K 20W – 60K
Wavelength (nm) 355
Average Power (Watts) >15W@50KHz >20W@60KHz
Energy (µJ) >300 >330
Specified Repetition Rate(kHz) 50 60
Repetition Rate (kHz) 30~150
Pulse Width (ns) <15 <20
Beam Quality (M²) <1.2
Beam Roundness (%) >90
Beam Diameter (mm) 0.4~0.8
Beam Divergence (mRad) <1.5
Point Stability (µRad/°C) <20
Polarization Ratio 100:1 Linear, Horizontal
Pulse-to-Pulse Stability (% RMS) <3
Average Power Stability (% over 12 hours) <3
Cold Start Warm-Up (mins.) <20
Standby Warm-Up (mins.) <10
Operational Temperature Range (°C) 0-35°C
Operation Humidity Range (%) 20 to 80, non-condensing
Storage Temperature Range (°C) -20 to 50
Storage Humidity Range (%) 20 to 80, non-condensing
Input Voltage (VDC)/Rated Power(W) 24/300
Communication RS232
Cooling Water
Weight (kg) 7.1
