AOFlex Mopa Series

Advanced Optowave’s AOFlex Fiber MOPA Laser Series—designed to deliver superior performance, reliability, and versatility for demanding applications.

  • Up to 1kW Power – High output ensures maximum efficiency for industrial and scientific applications.
  • Exceptional Reliability – Engineered for long-term stability with minimal maintenance.
  • Adjustable Pulse Width (2ns–500ns) – Optimize performance for a wide range of materials and processes.
  • Outstanding Beam Quality – Achieve precise, clean results with superior energy control.
  • Advanced Control Interface – Seamless integration with automated systems for enhanced productivity.

The AOFlex series is built to empower your manufacturing, marking, and processing needs with unmatched precision and stability. Whether you require high-speed marking, deep engraving, or intricate micromachining, AOFlex is the solution you can trust.

AOFlex Mopa Series
Specification 20 30 100
Wavelength (nm) 1060∼1080
Average Power (W) 20 30 100
Beam Quality (M²) <1.5 <1.6
Max Pulse Energy (mJ) 0.8 2.0
Repetition Rate (kHz) 1∼3000
Pulse Duration (ns) 2∼500
Beam Diameter (mm) 7±1
Laser Switching ON/OFF Time (μs) <50 <20
Power Instability (%RMS) <5
Dimension (mm) 269*210*69 360*301*114
Net Weight (kg) <4.5 <13
Supply Voltage (V) 24 (DC) 48 (DC)
Recommended Power Supply (W) 150 600
Cooling Air



AOFlex Mopa Series
Specification 200 300 500 750 1000
Wavelength (nm) 1060∼1080
Average Power(W) 200 300 500 750 1000
Beam Quality (M²) <1.6 <1.8 <2.0
Max Pulse Energy (mJ) 2.0
Repetition Rate (kHz) 1∼3000 1∼4000 1∼6000
Pulse Duration (ns) 2∼500 20∼500
Beam Diameter (mm) 7±1 (10mm optional) 9∼11
Laser Switching ON/OFF time (μs) <20
Power Instability (%RMS) <5
Dimension (mm) 425*360*135 448*439*135 485*461*82 692*485*130
Net Weight (kg) <21 <26 <23 <45
Supply Voltage (V) 48 (DC) 220 (DC)
Recommended Power Supply (W) 1000 1500 2500 2640 3520
Cooling Air Water
